THM hammer mills with blower

THM type For short conveyor up to 12 m (suction and pressure pipe). THM-D type The enhanced blower ensures that the goods to be milled are sucked up over long distances and that the feed is conveyed over long distances to the point of consumption. The maximum conveyor distance is 50 m (suction and pressure pipe). THM-DS Type An even stronger blower is incorporated in an even larger milling casing, which enables systems with a total pipe length of up to 80 m.

Product overview

Technical data

Type
Power [kW]
max. conv. path [m]
Tube-Ø [mm]
THM 75/25
7,5
20
75
THM 90/15
11,0
15
90
THM 90/30
11,0
30
90
THM 90/60
11,0
60
90
THM 110/30
15,0
30
110
THM 110/30
18,5
30
110
THM 110/30
22,0
30
110
THM 110/60
15,0
60
110
THM 110/60
18,5
60
110
THM 110/60
22,0
60
110
